Подробная информация о продукте:
|
|
| Место происхождения: | СДЕЛАНО В КИТАЕ |
|---|---|
| Фирменное наименование: | Btutest |
| Сертификация: | SGS, INTERTEK |
| Номер модели: | БТУ-ВЭС |
|
Оплата и доставка Условия:
|
|
| Количество мин заказа: | 1 |
| Цена: | Возможен торг |
| Упаковывая детали: | LC, D/A, D/P, T/T, Western Union, MoneyGram |
| Время доставки: | 5-8 рабочих дней |
| Условия оплаты: | LC, D/A, D/P, T/T, Western Union |
| Поставка способности: | 3000 комплектов в месяц |
|
Подробная информация |
|||
| Название продукта: | Гидравлическая универсальная испытательная машина с компьютерным управлением | Максимальная сила: | 100 кН |
|---|---|---|---|
| Максимальное пространство сжатия: | 500 мм | Максимальное пространство натяжения: | 600 мм |
| Ход поршня: | 200 мм | ||
Характер продукции
Character count: 124
| Feature | Product Advantage | Customer Benefit |
| Four/six‑column high‑stiffness frame | Better axial & lateral stiffness, precise alignment | Reliable test results, minimal deflection under high loads |
| Dual‑space design (tension upper / compression lower) | No need to change fixtures between different tests | Saves time, increases daily test throughput (up to 40% efficiency gain) |
| Extra large test space (up to 1000 mm tensile) | Accommodates long specimens, large components | One machine handles more sizes – no need for custom equipment |
| Long piston stroke (200 mm) | Handles large deformation and long specimens | Versatile – suitable for both short and long samples |
| Accuracy Class 1 (Class 0.5 optional) | Meets EN ISO 6892-1, ASTM A370, etc. | Data accepted globally, pass audits with confidence |
| Concrete testing capability | Compression & flexure tests on concrete cubes/cylinders | One machine for metals and concrete – cost effective |
| Hydraulic gripping (standard/optional) | Strong, stable clamping force, no specimen slippage | Operator‑friendly, consistent results, reduces fatigue |
| Powerful software + remote support | Cyclic, creep, relaxation, holding; automatic data analysis; remote updates | Advanced testing for R&D; reduced downtime; customizable reports |
| Overload protection limit sensor | Automatic stop at set limits | Protects machine and operator, reduces downtime |
| Wide model range (100–2000 kN) | Covers small rebar to heavy structural steel | Choose exactly the capacity you need – no waste |
| SGS & CE certified | Third‑party quality verification | Builds trust with international buyers, easier market access |
| Standard | Material / Application | Why It Matters |
| EN ISO 6892‑1 | Tensile testing of metals | Mandatory for Europe, Middle East, Asia |
| EN ISO 15630‑1 | Test methods for steel for concrete reinforcement | Essential for rebar suppliers to EU projects |
| EN ISO 7500‑1 | Calibration of testing machines (force) | Proves force traceability |
| EN 10002 | Tensile testing (historical standard) | Compatibility with older specifications |
| ASTM A370 | Mechanical testing of steel products | Required for North American buyers |
| UNI 7676 | Italian metal tensile standard | Key for Italian market |
“We can pre‑install test templates for ISO, ASTM, EN, and other standards. One‑click switch between standards in the software.”
| Parameter | WES-100B | WES-300B | WES-600B | WES-1000B | WES-2000B |
| Max Force (kN) | 100 | 300 | 600 | 1000 | 2000 |
| Accuracy Class | Class 1 (0.5 opt.) | same | same | same | same |
| Max Compression Space (mm) | 500 | 600 | 600 | 600 | 850 |
| Max Tensile Space (mm) | 600 | 700 | 700 | 700 | 1000 |
| Piston Stroke (mm) | 200 | 200 | 200 | 200 | 200 |
| Round Specimen Range (mm) | Φ6–22 | Φ10–32 | Φ13–40 | Φ13–40 | Φ16–80 |
| Flat Specimen Thick (mm) | 0–15 | 0–20 | 0–20 | 0–40 | 0–50 |
| Compression Plate Diameter (mm) | Φ110 | Φ150 | Φ200 | Φ225 | Φ225 |
| Main Frame Dimensions (mm) | 500×700×1740 | 760×565×1960 | 760×565×2110 | 870×635×2260 | 1300×900×3300 |
| Control Cabinet (mm / kg) | 640×590×1400 / 300kg | same | same | same | same |
| Main Frame Weight (kg) | 1400 | 1600 | 2000 | 3000 | 8000 |
Quick selection guide:
Standard accessories (included):
Optional accessories:
Service & support:
“We are the direct manufacturer. Factory price, direct support, faster spare parts delivery.”
| Scenario | Point | Recommended Model | Key Advantage |
| Construction material lab | Test rebar, concrete, structural steel – need both metal and concrete capability | WES-600B / 1000B | One machine for metals & concrete; dual‑space saves time |
| Large infrastructure project | Long rebar (up to 1000 mm), heavy steel sections | WES-2000B | 1000 mm tensile space, 2000 kN capacity, six‑column stability |
| Third‑party testing lab | High volume, need reliability, concrete & metal testing | WES-1000B / 2000B | Wide capacity range, SGS certified, easy calibration |
| University teaching & research | Demonstrate tension, compression, bending, and concrete tests | WES-300B / 600B | Versatile, dual‑space, powerful software for R&D |
| Precast concrete plant | Test rebar tensile + concrete cube compression | WES-600B | Concrete plates available; one machine, two applications |
| Steel fabrication / heavy machinery | Thick plate (up to 50 mm), large diameter round bars (Φ80 mm) | WES-2000B | Wide gripping range (Φ16–80 mm, 0–50 mm flat) |
Case 1 – Large Infrastructure Project in Nigeria
Machine: WES-2000B
“We test long rebar (up to 900 mm) and heavy steel sections for a bridge project. The 1000 mm tensile space and 2000 kN capacity are perfect. Six‑column frame gives extremely stable results.”
– Project Quality Manager
Case 2 – Precast Concrete Plant in Philippines
Machine: WES-600B
“We test both rebar tensile and concrete cubes on the same machine. The concrete compression plates work great. Saved us the cost of buying two separate machines.”
– Plant Engineer
Case 3 – University Civil Engineering Lab in Indonesia
Machine: WES-300B
“Students learn tension, compression, bending, and even concrete tests using one machine. The software automatically calculates yield strength and modulus – very helpful for teaching.”
– Lab Coordinator
Case 4 – Third‑Party Testing Lab in Saudi Arabia
Machine: WES-1000B
“We process over 300 samples weekly – rebar, plate, concrete. Dual‑space design eliminates fixture change time. SGS certification helped us win government contracts.”
– Lab Director
Case 5 – Steel Fabricator in Mexico
Machine: WES-600B
“We upgraded from an old single‑space machine. The dual‑space design saves us at least 2 hours every day. Hydraulic jaws make operation effortless even for thick plates.”
– Quality Supervisor
✅Factory direct price– no middleman markup.
✅12 months warranty + lifetime technical support– we stand behind our machine.
✅Quick delivery– 30–45 days for standard models.
✅Free sample testing– available upon request.
✅SGS & CE certified– quality you can trust.
✅One machine for metals & concrete– maximize your ROI.
��Click “Contact Supplier” nowand tell us:
• What materials/specimens you test (rebar, concrete, plate, bolt, etc.)
• Maximum force required (kN)
• Any special standard (ASTM, ISO, EN, etc.)
We will reply within 2 hours with a recommendation and quotation.
“Btutest – your reliable partner in material testing since 2010.”
